产品特点：
♣大屏幕液晶显示，显示分辨率0.001℃，温度全量程提供稳定的恒温系统
♣温度测量值偏差可修正，温度显示精度可达0.001℃，上下限温度报警可设定
♣采用高精度软件、操作简便，温度稳定性强，P、I、D自动整定或人工调整
♣可选配RS232或RS485通讯接口，实现数据传输进行远距离控制
技术参数：
型号 | 控温范围 | 波动度 ℃ | 分辨率 | 容积 | 深度 | 槽开口 | 外型尺寸mm |
GJC-06A | RT+10~100℃ | 0.002~0.005 | 0.001℃ | 6L | 150mm | 190*160mm | 245*370*400 |
GJC-06B | RT+10~200℃ | 0.005~0.02 | 0.001℃ | 6L | 150mm | 190*160mm | 245*370*410 |
GJC-10A | RT+10~100℃ | 0.002~0.005 | 0.001℃ | 10L | 200mm | 190*160mm | 245*370*400 |
GJC-10B | RT+10~200℃ | 0.005~0.02 | 0.001℃ | 10L | 200mm | 190*160mm | 245*370*460 |
GJC-15A | RT+10~100℃ | 0.002~0.005 | 0.001℃ | 15L | 200mm | 235*180mm | 320*370*450 |
GJC-15B | RT+10~100℃ | 0.002~0.005 | 0.001℃ | 15L | 250mm | 190*160mm | 245*370*500 |
GJC-15C | RT+10~200℃ | 0.005~0.02 | 0.001℃ | 15L | 250mm | 190*160mm | 245*370*510 |
GJC-15D | RT+10~200℃ | 0.005~0.02 | 0.001℃ | 15L | 200mm | 235*180mm | 320*370*460 |
GJC-20A | RT+10~100℃ | 0.002~0.01 | 0.001℃ | 20L | 150mm | 320*300mm | 390*490*420 |
GJC-20B | RT+10~200℃ | 0.005~0.02 | 0.001℃ | 20L | 150mm | 320*300mm | 390*490*430 |
GJC-25A | RT+10~100℃ | 0.002~0.005 | 0.001℃ | 25L | 300mm | 235*180mm | 320*370*570 |
GJC-25B | RT+10~200℃ | 0.005~0.02 | 0.001℃ | 25L | 300mm | 235*180mm | 320*370*580 |
GJC-30A | RT+10~100℃ | 0.002~0.005 | 0.001℃ | 30L | 230mm | 320*300mm | 390*490*505 |
GJC-30B | RT+10~200℃ | 0.005~0.02 | 0.001℃ | 30L | 230mm | 320*300mm | 390*490*515 |
GJC-40A | RT+10~100℃ | 0.002~0.01 | 0.001℃ | 40L | 200mm | 400*380mm | 510*620*500 |
GJC-40B | RT+10~200℃ | 0.005~0.02 | 0.001℃ | 40L | 200mm | 400*380mm | 510*620*510 |
GJC-50 | RT+10~100℃ | 0.002~0.005 | 0.001℃ | 50L | 300mm | 300*350mm | 405*605*585 |
GJC-70 | RT+20~100℃ | 0.002~0.01 | 0.001℃ | 70L | 300mm | 600*300mm | 400*1100*450 |
GJC-90 | RT+20~100℃ | 0.002~0.01 | 0.001℃ | 90L | 300mm | 800*300mm | 400*1300*450 |
备注 | 循环方式全部为内循环 | ||||||
